Possible areas of application
Battery Specifications
| Cell Chemistry | LFP | |||||
| Cooling | Natural (Electric Heating) | |||||
| Battery Capacity (Ah) | 206 | 277 | ||||
| Power Output (kWh) | 21 | 33 | 31 | 21 | 29 | 32 |
| Nominal Voltage (V) | 106 | 144 | 154 | 77 | 106 | 116 |
| Cell Configuration | 1P33S | 1P45S | 1P48S | 1P24S | 1P33S | 1P36S |
| Maximum Charging Current (A) | 206 | 250 | ||||
| Maximum discharge rate (A) | 206 | 250 | ||||
| Dimensions (L x 630 x 240) mm | 820 | 1010 | 1060 | 820 | 1010 | 1060 |
| Weight (Kg) | 205 | 219 | 233 | 201 | 220 | 235 |
| Protection Class | IP54 | |||||
| Communication | CAN | |||||
